4. Slide the drive into the drive bay (1) and install the four 6-32 mounting screws (2) to secure the
drive in place.
NOTE: HP has supplied four extra 6-32 mounting screws on the front of the chassis behind the
bezel. Refer to
Drives on page 59 for an illustration of the extra mounting screws location. When
replacing a hard drive, use the four 6-32 mounting screws that were removed from the old drive to
install the new one.
72 Chapter 5 Removal and replacement procedures: Microtower
