HP ProDesk 600 G2 Desktop Mini Service Manual

Rear panel components (EliteDesk 800, EliteDesk 705, ProDesk
600, and HP MP9)
NOTE: Your computer model may look slightly dierent from the illustration in this section.
1 External Antenna Connector (optional) 8 VGA Monitor Connector
2 Thumbscrew 9 DisplayPort (default, shown), HDMI, or Serial
Connector
3 Padlock Loop 10 USB 3.0 Ports (2) (blue)
4 Cable Lock Slot 11 USB 3.0 Ports (2) (blue) with support for wake
from S4/S5 power states (not for 705 models)
NOTE: On 705 models this is a USB 2.0 port
that supports only the S4 power state.
5 External Antenna Connector (optional) 12 RJ-45 Network Connector
6 Wireless antenna 13 Power Connector
7 DisplayPort Monitor Connector
Rear panel components (EliteDesk 800, EliteDesk 705, ProDesk 600, and HP MP9) 3

HP ProDesk 600 G2 Desktop Mini Specifications

General

Graphics	Intel HD Graphics 530
Chipset	Intel Q150
Power Supply	65 W external power adapter
Processor	Intel Core i3/i5/i7 (6th Gen)
RAM	Up to 32 GB DDR4 SDRAM 2133 MHz
Storage	500GB HDD / 128GB SSD / 256GB SSD / 512GB SSD / 1TB HDD
Operating System	Windows 10 Pro 64
Network	Intel Ethernet I219-LM Gigabit Network Connection
Dimensions	17.7 x 17.5 x 3.4 cm
Weight	1.3 kg
Ports	4 x USB 3.0, 2 x USB 2.0, 1 x HDMI, 1 x DisplayPort, 1 x VGA, 1 x RJ-45, 1 x headphone/microphone combo jack
