HP ProDesk 600 G2 Desktop Mini Service Manual

Processor – Intel models
Description
Intel Core i7-6700
Intel Core i7-6700T
Intel Core i5-6600
Intel Core i5-6600T
Intel Core i5-6500
Intel Core i7-6500T
Intel Core i3-6320
Intel Core i3-6300T
Intel Core i3-6100T
Intel Pentium G4500T
Intel Pentium G4400T
Intel Pentium G4400TE (MP9 G2 models only)
Intel Celeron G3900T
Intel Pentium G3900TE (MP9 G2 models only)
1. Prepare the computer for disassembly (Preparation for disassembly on page 20).
2. Remove the top cover (Top cover on page 21).
3. Remove the fan (Fan on page 37).
4. Remove the heat sink (Heat sink on page 43).
5. Rotate the locking lever to its full open position (1).
6. Raise and rotate the microprocessor retainer to its fully open position (2).
Processor – Intel models 45

HP ProDesk 600 G2 Desktop Mini Specifications

General

Graphics	Intel HD Graphics 530
Chipset	Intel Q150
Power Supply	65 W external power adapter
Processor	Intel Core i3/i5/i7 (6th Gen)
RAM	Up to 32 GB DDR4 SDRAM 2133 MHz
Storage	500GB HDD / 128GB SSD / 256GB SSD / 512GB SSD / 1TB HDD
Operating System	Windows 10 Pro 64
Network	Intel Ethernet I219-LM Gigabit Network Connection
Dimensions	17.7 x 17.5 x 3.4 cm
Weight	1.3 kg
Ports	4 x USB 3.0, 2 x USB 2.0, 1 x HDMI, 1 x DisplayPort, 1 x VGA, 1 x RJ-45, 1 x headphone/microphone combo jack
