HP ProDesk 600 G2 Desktop Mini Service Manual

Misc parts
Item Description
(1) Heat sink
(2) Fan
(3) Secondary hard drive fan (for use in EliteDesk 800 and MP9, 65W models)
(4) Speaker
(5) Power switch/light cover
(6) Option board, HDMI
(7) Option board, serial port
* Option board, DisplayPort (not illstrated)
(8) Thermal sensor
(9) Hood sensor assembly
* Stand
* Port cover
* HP Ultraslim Keyed Cable Lock
Desktop Mini (DM) chassis spare parts 9

HP ProDesk 600 G2 Desktop Mini Specifications

General

Graphics	Intel HD Graphics 530
Chipset	Intel Q150
Power Supply	65 W external power adapter
Processor	Intel Core i3/i5/i7 (6th Gen)
RAM	Up to 32 GB DDR4 SDRAM 2133 MHz
Storage	500GB HDD / 128GB SSD / 256GB SSD / 512GB SSD / 1TB HDD
Operating System	Windows 10 Pro 64
Network	Intel Ethernet I219-LM Gigabit Network Connection
Dimensions	17.7 x 17.5 x 3.4 cm
Weight	1.3 kg
Ports	4 x USB 3.0, 2 x USB 2.0, 1 x HDMI, 1 x DisplayPort, 1 x VGA, 1 x RJ-45, 1 x headphone/microphone combo jack
