1-4 HP ProLiant BL e-Class C-GbE Interconnect Switch Menu-driven Interface Reference Guide
HP CONFIDENTIAL Codename: DeLorean Part Number: 322858-001 Last Saved On: 2/4/03 11:53 AM
Navigation Features
Use the features in Table 1-1 to navigate through the screens.
Table 1-1: Menu-driven interface Navigation
To Action
Toggle between the field options Highlight items in <angle brackets>, and then press the
spacebar.
Enter data in a field Highlight the item in [square brackets], and then type in
the new data.
Execute a command Highlight the command displayed in UPPERCASE
letters, and then press the Enter key.
Move between fields on a screen
Press the Page Up and Page Down keys, the left and
right arrow keys, the Tab key, or the Backspace key.
Display the previous screen
Press the Esc key.
Display the main menu
Press the Ctrl+T keys.
Refresh the screen display
Press the Ctrl+R keys.
Display the next page of information
Press the N key.
Display the previous page of information
Press the P key.
Help and System Messages
The bottom section of each screen displays field-level help and system messages.
•
•
Function—Displays field-level help.
Message—Displays system messages.
Configuring the Switch Modules
After logging on to the interconnect switch for the first time, perform the following tasks for
each switch module:
1. Configure the IP address
2. Set up users, passwords, and access privileges
3. Change default SNMP community strings for read/write and read-only
For information on how to configure these and other interconnect switch features, refer to
Chapter 2.
NOTE: After configuring the IP address on the switch module, the switch module can be accessed
using Telnet, SNMP, or a Web browser. Refer to the section, “Configuring the Remote Management IP
Interface Settings,” in Chapter 2 for information on how to set up the IP address.
