Configuring the Switch Modules using the Menu-driven Interface
Characteristics of DEFAULT_VLAN include:
•
•
•
•
•
•
•
•
•
DEFAULT_VLAN is an IEEE 802.1Q Static VLAN with VID equal to 1.
DEFAULT_VLAN cannot be deleted.
The VID cannot be changed. The VID that is equal to 1 is reserved for
DEFAULT_VLAN.
The VLAN name can be changed to any other valid VLAN name.
You cannot delete a port from DEFAULT_VLAN, unless it is a member of another
802.1Q VLAN.
You cannot forbid a port from DEFAULT_VLAN, unless it is a member of another
802.1Q VLAN.
If a port is deleted from the only 802.1Q VLAN of which it is a member, then it will
automatically become a member of DEFAULT_VLAN as an untagged, egress port.
If a port is assigned to a user-created 802.1Q VLAN, and is not a tagged egress port
member of DEFAULT_VLAN (in other words, it is an untagged egress port), then it will
be deleted automatically from DEFAULT_VLAN.
A tagged egress port of DEFAULT_VLAN will not be deleted from DEFAULT_VLAN,
when it is assigned to another user-created 802.1Q VLAN.
To edit VLAN definitions and to configure port settings for IEEE 802.1Q VLAN support:
1. Highlight Configure VLANs on the Configuration menu.
2. Press the Enter key. The following screen is displayed.
HP ProLiant BL e-Class C-GbE Interconnect Switch Menu-driven Interface Reference Guide 2-27
HP CONFIDENTIAL Codename: DeLorean Part Number: 322858-001 Last Saved On: 2/4/03 11:56 AM
