HP ProLiant DL320e Gen8 v2 User Manual

Setup 27
CAUTION: Always plan the rack installation so that the heaviest item is on the bottom of the rack.
Install the heaviest item first, and continue to populate the rack from the bottom to the top.
To install the server in an HP, Compaq-branded, Telco, or a third-party rack:
1. Install the server and cable management arm option into the rack. See the documentation that ships with
the Quick Deploy Rail System.
WARNING:
To reduce the risk of electric shock, fire, or damage to the equipment, do not plug
telephone or telecommunications connectors into RJ-45 connectors.
2. Connect peripheral devices to the server. For information on identifying connectors, see "Rear panel
components (on page 7)."
3. Connect the power cord to the server.
4. Connect the power cord to the power source.
WARNING: To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
5. Install the rack rail cable ties ("Installing the rack rail cable ties" on page 27).
Installing the rack rail cable ties
1. Install the server into the rack ("Installing the server into the rack" on page 26).
2. Connect the power cord to the server.
3. Connect the network and peripheral cables to the server.
4. Install the rack rail cable ties:
a. Hold the network and peripheral cables parallel to the rack rail, and then wrap the cable tie around
the rack rail.
CAUTION: To prevent thermal or mechanical obstruction on full-length servers installed in the
rack, the extra length and buckle part of the cable tie must be facing the outside of the rack rail.

HP ProLiant DL320e Gen8 v2 Specifications

General

Processor	Intel Xeon E3-1200 v3 series
Processor Sockets	1
Memory	Up to 32GB
Memory Slots	4
Form Factor	1U Rack
Memory Type	DDR3 UDIMM
Storage	Up to 4 LFF or 8 SFF drives
RAID Support	HP Dynamic Smart Array B120i
Expansion Slots	1 PCIe 3.0
Management	HP iLO
