HP ProLiant DL320e Gen8 v2 User Manual

Hardware options installation 51
c.
Use the chassis cable clip to secure the excess length of the internal USB connector cable.
8. If removed, install the PCI riser cage (on page 20).
9. Install the access panel (on page 17).
10. Do one of the following:
o Slide the server into the rack.
o Install the server into the rack ("Installing the server into the rack" on page 26).
11. Connect the peripheral devices to the server.
12. Connect the power cord to the server.
13. Connect the power cord to the power source.
14. Power up the server (on page 14).
HP Trusted Platform Module option
For more information about product features, specifications, options, configurations, and compatibility, see
the product QuickSpecs on the HP website (http://www.hp.com/go/qs).
Use these instructions to install and enable a TPM on a supported server. This procedure includes three
sections:
1. Installing the Trusted Platform Module board (on page 52).
2. Retaining the recovery key/password (on page 54).
3. Enabling the Trusted Platform Module (on page 54).
Enabling the TPM requires accessing RBSU ("HP ROM-Based Setup Utility" on page 71). For more
information about RBSU, see the HP website (http://www.hp.com/support/rbsu).
TPM installation requires the use of drive encryption technology, such as the Microsoft Windows BitLocker
Drive Encryption feature. For more information on BitLocker, see the Microsoft website
(http://www.microsoft.com).
CAUTION: Always observe the guidelines in this document. Failure to follow these guidelines
can cause hardware damage or halt data access.

HP ProLiant DL320e Gen8 v2 Specifications

General

Processor	Intel Xeon E3-1200 v3 series
Processor Sockets	1
Memory	Up to 32GB
Memory Slots	4
Form Factor	1U Rack
Memory Type	DDR3 UDIMM
Storage	Up to 4 LFF or 8 SFF drives
RAID Support	HP Dynamic Smart Array B120i
Expansion Slots	1 PCIe 3.0
Management	HP iLO
