Hardware options installation 40
a.
Open the capacitor pack holder.
b. Position the capacitor pack in the holder.
c. Close the capacitor pack holder.
CAUTION: When connecting or disconnecting the capacitor pack cable, the connectors on the
cache module and cable are susceptible to damage. Avoid excessive force and use caution to
avoid damage to these connectors.
7. Connect the capacitor pack cable to the cache module.
