Cabling 58
Item Description
1
Power cable
2
Mini-SAS cable
• Mini-SAS cable connected to a storage controller in the full-height expansion slot
Item Description
1
Power cable
2
Capacitor pack cable
3
Mini-SAS cable
The HP 750 W CS -48 V DC Power Supply (94% efficiency) with PDB is used in the following drive
configurations:
• Mini-SAS cable connected to the system board
