Cabling 109
o Connect to an HPE 12G SAS Expander Card
Express Bay Enablement Option cabling options
The Express Bay Enablement option has several options for cabling, depending on the configuration:
• 8SFF drive cage installed in bay 1
• 8SFF drive cage installed in bay 1 and 2SFF drives in the rear of the server
• Drive bay 1 is empty
• 8SFF drive cage installed in bay 1 and 2 SFF drives in the front of the server
