Removal and replacement procedures 26
CAUTION: To prevent damage to the server, ensure that all DIMM latches are in closed and
locked position before installing the fans.
To remove the component:
1. Unlock and remove the tower bezel ("Remove the tower bezel" on page 23).
2. Power down the server (on page 23).
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Place the server on its side.
5. Remove the access panel (on page 24).
6. If installed, remove the PCI air baffle (on page 25).
7. Remove the system air baffle (on page 24).
8. Remove the fans.
o Single-processor configuration
