Removal and Replacement Procedures

2-10 HP ProLiant ML150 Generation 2 Server Maintenance and Service Guide

HP CONFIDENTIAL Codename: Stone Soup 2 Part Number: 368148-003 Last Saved On: 6/10/05 4:28 PM

Diskette Drive Signal Cable

Figure 2-5: Diskette drive signal cable routing

SCSI Hot-Plug Hard Drive Cable

Figure 2-6: SCSI hot-plug hard drive cable routing
