Physical and Operating Specifications
HP ProLiant ML150 Generation 2 Server Maintenance and Service Guide 5-3
HP CONFIDENTIAL Codename: Stone Soup 2 Part Number: 368148-003 Last Saved On: 4/19/05 5:18 PM
Memory
Table 5-2: Memory Specifications
Item Description
Size 512 MB, 1 GB and 2 GB
Speed 333 MHz
Type PC2700 ECC Registered DDR SDRAM DIMMs
Note: DIMMs must be industry-standard 184-pin PC2700 DDR DIMMs. The DDR DIMMs must
support CAS Latency 2 or greater. They must also contain the mandatory Joint Electronic Device
Engineering Council (JEDEC) Serial Presence Detect (SPD).
1.44-MB Diskette Drive
Table 5-3: 1.44-M Diskette Drive Specifications
Item Description
Size 88.9 mm (3.5 in)
LED (front panel) Green
Read/write capacity per diskette
(high/low density)
1.44 MB/720 KB
Drives supported 1
Drive height 15.2 mm (0.6 inch)
Drive rotation 300 rpm
Transfer rate bits/sec (high/low) 500/250 Kbps
Bytes/sector 512
Sectors/track (high/low) 18/9
Tracks/side (high/low) 80/80
Access times
Track-to-track (high/low) 6 ms/3 ms
Average (high/low) 174 ms/94 ms
Settling time 15 ms
Latency average 100 ms
Cylinders (high/low) 80/80
Read/write heads 2
