HP ProLiant ML150 Generation 2 - SCSI Non-Hot-Plug Hard Drive Cable; SATA Hot-Plug Hard Drive Cable

Removal and Replacement Procedures
HP ProLiant ML150 Generation 2 Server Maintenance and Service Guide 2-11
HP CONFIDENTIAL Codename: Stone Soup 2 Part Number: 368148-003 Last Saved On: 6/10/05 4:28 PM
SCSI Non-Hot-Plug Hard Drive Cable
Figure 2-7: SCSI non-hot-plug hard drive cable routing
SATA Hot-Plug Hard Drive Cable
Figure 2-8: SATA hot-plug hard drive cable routing
