Removal and Replacement Procedures
HP ProLiant ML150 Generation 2 Server Maintenance and Service Guide 2-49
HP CONFIDENTIAL Codename: Stone Soup 2 Part Number: 368148-003 Last Saved On: 6/10/05 4:28 PM
4. Press the battery release lever away from the battery (1).
5. Lift the battery up from that side and out of its holder (2).
NOTE: If expansion boards are installed, you may need to remove them to gain access to the battery.
Figure 2-47: Locating and removing a system board battery
To replace the system board battery, reverse steps 2 through 5.
IMPORTANT: The battery should be installed with the positive polarity (+ side) positioned up.
