Connectors, Jumpers, and LEDs
4-4 HP ProLiant ML150 Generation 2 Server Maintenance and Service Guide
HP CONFIDENTIAL Codename: Stone Soup 2 Part Number: 368148-003 Last Saved On: 4/19/05 5:18 PM
Table 4-2: System Board Components continued
Item Description Item Description
21 PCI slot 4 (64-bit PCI-X) 31 DIMM slot 2
22 Winbond Super I/O chipset 32 DIMM slot 1
23 ATI Rage XL graphic chipset 33 USB 2.0 ports (black)
24 PCI slot 5 (32-bit) 34 10/100/1000 LAN port (RJ-45)
25 PCI slot 6 (PCI-E x4) 35 Monitor port (blue)
26 Intel north bridge chipset 36 Parallel port (burgundy)
27 3-pin system fan connector 37 Serial port (teal)
28 Broadcom GbE LAN chipset 38 PS/2 mouse port (green)
29 DIMM slot 4 39 PS/2 keyboard port (purple)
30 DIMM slot 3

HP ProLiant ML150 Generation 2 Specifications

General

Processor Sockets	2
Form Factor	Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
CPU	Intel Xeon processor
Memory Slots	6
Storage	Serial ATA (SATA) or Serial Attached SCSI (SAS) depending on configuration
Expansion Slots	6
