HP R3000 User Manual

Installation 30
Connecting and securing the power cords
Installing the ERM in a rack
Before installing the unit, review and adhere to all warnings provided in "Precautions (on page 13)."
WARNING: A risk of personal injury or damage to the equipment exists. Uneven loading of
equipment in the rack might cause the rack to become unstable. Install the heavier
components first, and then continue to populate the rack from the bottom to the top.
1. Install the mounting rails ("Installing the mounting rails" on page 14).
2. Install the mounting ears on the chassis using the screws provided.
3. With one person on each side, lift the chassis to rail level and slide the chassis on the mounting rails.

HP R3000 Specifications

General

Model	R3000
Capacity	3000 VA / 2700 W
Rack Size	2U
Frequency	50/60 Hz
Output Voltage	230V
Input Voltage	230V
Battery Type	Sealed Lead Acid (SLA)
Interface	Serial, USB
Output Connections	IEC 320 C13, IEC 320 C19
Transfer Time	4 ms
Efficiency	95%
Operating Temperature	0°C to 40°C
Storage Temperature	-15°C to 45°C
Humidity	5% to 95% non-condensing
Dimensions	432 x 88 x 650 mm
