Overview
1-6 HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
7
1
4
5
3
2
6
Figure 1-4: Rear panel of T1500 XR NA
1 Communications port/option slot
2 Network Transient Protector OUT jack
3 Network Transient Protector IN jack
4 Load segment 1 (three NEMA 5-15 receptacles)
5 Load segment 2 (three NEMA 5-15 receptacles)
6 Power cord with NEMA 5-15 plug
7 ERM connector
