7
1
4
3
2
5
6
Figure 1-5: Rear panel of T1500 XR JPN
1 Communications port/option slot
2 Network Transient Protector OUT jack
3 Network Transient Protector IN jack
4 Load segment 1 (three NEMA 5-15 receptacles)
5 Load segment 2 (three NEMA 5-15 receptacles)
6 Power cord with NEMA 5-20 plug
7 ERM connector
