Product features
Exploded view
The following image shows a typical HP xw8400 Workstation. Drive configurations can vary.
For complete and current information on supported accessories and components, see
http://partsurfer.hp.com.
Figure 1-1 Exploded view
Table 1-1 Exploded view
Item Description Item Description
1 PCI card support 10 Memory modules
2 Power supply 11 Card guide/Front fan (fan is optional)
3 CPU heatsinks 12 Graphics card
4 Processors 13 Optical drive*
5 System fan 14 PCI-E card
6 Access panel 15 Diskette drive
7 System board 16 PCI card
8 Chassis 17 Hard drive
9 Front bezel
* A CD-ROM is an example of an optical drive.
2 Chapter 1 Product overview ENWW
