3. Push in on the green drivelock release tabs, and pull the hard drive out of the chassis.
Figure 4-36 Removing the hard drive
Installing a hard drive
1. Select a drive bay in which to install the drive. If installing more than one hard drive, use the hard
drive order shown in the following image.
Figure 4-37 Identifying hard drive installation order
2. Squeeze the green tabs, and slide the rails out of the empty bay.
ENWW Removing and replacing components 83
