HP Z Workstation series User Manual

HP Z800 Workstation front panel components
The following illustration shows the front panel components of a typical HP Z800 Workstation. Drive
configurations can vary.
Figure 2-8 HP Z800 Workstation front panel
Table 2-8 HP Z800 Workstation front panel connectors
*
Item Symbol Description Item Symbol Description
1 Optical drive manual eject 6
Headphone connector
2 Optical drive eject button 7
Microphone connector
3
Power button 8 IEEE-1394a connector
4
Hard drive activity light 9 Optical drive activity light
5
USB 2.0 ports (3) 10 Optical Drive
*
Refer to the Maintenance and Service Guide for the workstation for specific front panel connector information.
ENWW HP Z800 Workstation components 17
