4. Disconnect the power cable (1) and data cable (2) from the hard drive.
Figure 9-6 Disconnecting power and data cables from the primary HDD
5. Press down on the green release latch next to the hard drive (1). While holding the latch down,
slide the drive forward until it stops, then lift the drive up and out of the bay (2).
Figure 9-7 Removing the primary hard drive
ENWW
Installing a hard disk drive
49
