HP Z210

8. Tighten each set of diagonally opposed screws a little at a time to 6 in-lbs of torque.
CAUTION: Do not overtighten the heatsink screws. Overtightening can strip the threads in the
chassis.
9. Connect the CPU heatsink fan connector to the system board.
Figure 5-40 Connecting the heatsink fan cable
100 Chapter 5 Replacing components ENWW
