HP Z210 User Manual

Downloading HP Vision Diagnostics
If for some reason neither Vision Creator nor HP Vision Diagnostics are available on your workstation,
follow these steps to download HP Vision Diagnostics from the HP Web site and load onto a USB flash
drive or DVD/CD:
1. Go to
http://www.hp.com/go/workstationsupport.
2. Select your workstation.
3. Click Download drivers and software.
4. Select your language and operating system.
5. Select the Diagnostic link.
6. Locate HP Vision Diagnostics under “Quick jump to downloads by category...” for either USB
or CD (as desired) and select Download.
7. Depending on whether you chose USB or DVD/CD:
a. USB: Run the .exe file that is downloaded, then follow the prompts to save HP Vision
Diagnostics and load it onto a USB flash key.
b. DVD/CD: Run the .exe file that is downloaded, then follow the installer prompts to extract
and save the .iso file to your hard drive. Use CD-ROM burning software to copy the .iso file
to an optical medium.
8. When the DVD/CD or USB flash drive has the utility installed, insert the USB flash drive or DVD/
CD into the computer (while it is on).
9. Shut down the workstation using the operating system.
10. Turn on the computer. The system should boot into HP Vision Diagnostics.
NOTE: If the system does not boot to the DVD/CD in the optical drive or to the USB flash drive,
you may need to change the boot order. You may use the Computer Setup (F10) utility to change
the boot order, or you may press F9 to select the appropriate boot device.
11. At the boot menu, select either the HP Vision Diagnostics utility to test the various hardware
components in the computer or the HP Memory Test utility to test memory only.
NOTE: The HP Memory Test is a comprehensive memory diagnostic utility that is run as a stand-
alone application, outside of HP Vision Diagnostics.
If the computer is booted from a DVD/CD, a separate boot DVD/CD will be required to use the
memory diagnostic. Hence, HP recommends that a USB key be used to boot the diagnostic
utilities. It is faster than using a DVD/CD, and it accommodates both the Memory Test and Vision
Diagnostics.
12. If running HP Vision Diagnostics, select the appropriate language and click Continue.
13. In the End User License Agreement page, select Agree if you agree with the terms. The HP Vision
Diagnostics utility launches with the Survey tab displayed
130 Chapter 6 Diagnostics and troubleshooting ENWW

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
