HP Z210

Workstation components
This section describes the workstation components, including front and rear panel components.
For complete and current information on supported accessories and components for the workstation,
see
http://partsurfer.hp.com.
Chassis components
The following figure shows the chassis components of a typical HP Z210 CMT Workstation layout.
Drive configurations can vary.
Figure 1-2 Workstation chassis components
Table 1-1 Workstation component descriptions
Item Description Item Description
1 Power supply 8 Memory module (DIMM)
2 Side access panel 9 PCIe card
3 Rear system fan 10 PCI card
4 Optical drive 11 Speaker
5 Processor heatsink 12 Hard disk drive
6 Processor (CPU) 13 Front bezel
7 System board 14 Chassis
