HP Z210 User Manual

Table 6-7 Diagnostic lights and audible codes
Activity Possible cause Recommended action
Blue Power LED
*
on. No
beeps.
Computer on.
N/A
Blue Power LED
*
blinks every
two seconds.
*
No beeps.
Computer in Sleep mode
(S3-Suspend to RAM). Select
models only.
Blue Power LED
*
is off.
*
No
beeps.
Computer in Hibernate
mode (S4-Suspend to disk)
or system is off (S5).
Blue Power LED
*
blinks three
times*, once per second.
*
No beeps.
Computer in Sleep mode
(S3-Suspend to RAM). Select
models only.
Blue Power LED
*
blinks four
times*, once per second.
*
No beeps.
Computer in Hibernate
mode (S4-Suspend to disk).
*User-selectable. See
The Computer Setup (F10) Utility
menu on page 28 for details.
For the following LED activity and beeps, the beeps are heard through the chassis speaker. Blinks and beeps repeat for 5 cycles, after
which, only the blinks continue to repeat.
Red Power LED blinks two
times, once every second,
followed by a two-second
pause. Two beeps.
CPU thermal protection
activated by either of the
following methods:
●
A fan might be blocked
or not turning.
●
The heatsink and fan
assembly is not
properly attached to
the CPU.
CAUTION: Internal components might be powered even when the
computer is off. To prevent damage, disconnect the computer power
cord before you remove a component.
1. Ensure that the computer air vents are not blocked and the cooling
fan is running.
2. Open the access panel, press power button, and verify that the CPU
fan is spinning. If the CPU fan is not spinning, make sure the fan
cable is plugged into the computer board header. Ensure the fan is
fully and properly seated or installed.
3. If fan is plugged in and seated properly, but is not spinning, the
problem might be in the CPU fan. Contact HP for assistance.
4. Verify that the fan assembly is properly attached. If problems
persist, there might be a problem with the CPU heatsink. Contact
HP for assistance.
Red Power LED blinks three
times, once every second,
followed by a two-second
pause. Three beeps.
CPU not installed (not an
indicator of bad CPU).
1. Verify that the CPU is present.
2. Reseat the CPU.
136 Chapter 6 Diagnostics and troubleshooting ENWW

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
