HP Z210 User Manual

Table 5-2 System board components ID
Item Component Item Component Item Component
1 Rear chassis fan 13 Battery 25 PCIe2 x1
2 CPU power 14
SATA ports
1
26 PCIe2 x16(4)
3 Solenoid hood lock 15 Clear CMOS button 27 PCIe2 x1
4 Chassis intrusion 16 Crisis recovery jumper 28 PCIe2 x16
5 CPU socket 17 Front chassis fan 29 PCIe2 x8(4)
6 CPU fan 18 System speaker 30 Audio
7 Memory sockets 19 3rd internal USB 31 USB
8 Main Power 20 Password jumper 32 Network/USB
9 Front power button/LED 21 Serial 33
DP display port
2
10 Front USB 22 Parallel 34
DVI —I video
2
11 1st internal USB/DASH 23 Front audio 35 Keyboard/mouse
12 2nd internal USB 24 PCI 32/33
1
Blue SATA ports, namely SATA0 and SATA1, support SATA Gen3 (6 Gb). Note that SATA5 is the only eSATA compatible
port.
2
Intel integrated HD video is supported on some workstation models, depending on installed CPU. Most supported Intel Core
processors support Intel HD Graphics 2000. Intel Xeon processors with model designations that end in "---5" support Intel HD
Graphics P3000. In Windows 7, you can view the model of CPU installed in the workstation by selecting Start > Control
Panel > System .
For related system architecture information, see System board architecture on page 1.
ENWW
Removing and installing components
61

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
