HP Z27U G3 User Manual

6
Rear and side components
To identify the components on the rear of the monitor, use this illustration and table.
Table 2-1 Rear and side components and their descriptions
Component
Description
(1)
OSD control
Activates the OSD buttons so that the button labels appear on the
right side of the screen.
(2)
Security cable slot
Connects an optional security cable.
(3)
Master power switch
Turns on or off all power to the monitor.
(4)
Power connector
Connects the power cord.
(5)
HDMI port
Connects the HDMI cable to a source device such as a computer.
(6)
DisplayPort connector
Connects the DisplayPort cable to a source device such as a
computer.
(7)
DisplayPort connector
OUT
Connects the DisplayPort cable from the monitor to a
secondary monitor.
(8)
USB Type-C port with DP
Alt Mode 1.4, USB
upstream data, and
maximum power
delivery up to 100 W
Connects the USB Type-C cable to a source device such as a
computer
Charges most USB Type-C devices even when the monitor is in
sleep mode
Note: The monitor must be set to Performance Mode.
This port also enables the USB Type-A ports to perform their
functions.
(9)
RJ-45 (network) jack
Connects an RJ-45 Ethernet network cable to the monitor.
(10)
USB port
Connects a USB cable to a peripheral device, such as a keyboard,
mouse, or USB hard drive.
(11)
USB port
Battery charging 1.2
Connects a USB cable to a peripheral device, such as a keyboard,
mouse, or USB hard drive and supports battery charging 1.2.

HP Z27U G3 Specifications

General

HD type	2K Ultra HD
Pixel pitch	0.233 x 0.233 mm
Screen shape	Flat
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	335.7 mm
sRGB coverage (typical)	99 %
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440
Product color	Black
Country of origin	China
Market positioning	Business
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	-5 - 20 °
Number of OSD languages	10
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
AC input voltage	100 - 240 V
Energy efficiency scale	A to G
Power consumption (max)	160 W
Power consumption (standby)	0.5 W
Power consumption (typical)	39 W
Sustainability certificates	ENERGY STAR, EPEAT Silver
Package depth	423 mm
Package width	698 mm
Package height	163 mm
Package weight	9400 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	205 mm
Width (with stand)	612.3 mm
Height (with stand)	530.4 mm
Weight (with stand)	6200 g
Depth (without stand)	38.9 mm
Height (without stand)	356.1 mm
Weight (without stand)	4700 g
