For more information, see the lock documentation.
21. Connect all peripheral cables to the server.
22. Connect the power adapter to the server, and then secure the power adapter cord in the power cord clamp.
23. Connect the power cord to the AC source.
24. Wait for 10 minutes for the server to reset and reinitialize the iLO configuration settings stored in SRAM.
IMPORTANT:IMPORTANT: If iLO security is disabled, the configuration will not be restored. To restore the configuration manually,
see https://www.hpe.com/support/ilo6https://www.hpe.com/support/ilo6.
25. Power up the server.
26. Properly dispose of the old battery.
For more information about proper battery disposal, contact an authorized reseller or an authorized service provider.
ResultsResults
The procedure is complete.
CablingCabling
This chapter includes cabling guidelines and diagrams for internal component cabling.
SubtopicsSubtopics
Cabling guidelinesCabling guidelines
Cabling diagramsCabling diagrams
Internal cabling managementInternal cabling management
Storage cablingStorage cabling
Serial port cablingSerial port cabling
Ambient temperature sensor cablingAmbient temperature sensor cabling
Fan cablingFan cabling
System power cablingSystem power cabling
Cabling guidelinesCabling guidelines
Observe the following:
For cable option kits, see the product QuickSpecs.
For cable spare part numbers, see the Illustrated parts catalog in the maintenance and service guide.
Some diagrams show alphabetical callouts such as A, B, C, etc. These callouts correspond to labels near the connectors on the cable.
Some cables have more than one connector, such as a Y-cable, but not all connectors are used.
The cable colors in the cabling diagrams used in this chapter are for illustration purposes only.
Observe all guidelines when working with server cables.
