HPE ProLiant Thin Micro TM200 - Remove the Server from the Wall Mount; Remove the Server from the Storage Expansion Unit

1
1
2
2
3
Remove the server from the wall mount
Procedure
1. Open the wall mount latch.
2. Remove the server from the wall mount.
1
2
2
3
Remove the server from the storage expansion unit
Prerequisites
Before you perform this procedure, make sure that you have a No. 2 Phillips screwdriver available.
Procedure
1. Hold the top side of the server and the bottom side of the storage expansion unit, and then carefully turn
the assembly over to access the bottom side of the storage expansion unit.
2. Remove the server from the storage expansion unit:
22 Remove the server from the wall mount
