Chapter 7 Elevator application guidance Shenzhen Hpmont Technology Co., Ltd.
―74― HD3L Series Controller User Manual
Ref. Code Function Value Remark
F04.04
Corresponding value of line 1 max.
setting
100.0%
F04.05 Line 2 min. setting 0.0%
F04.06
Corresponding value of line 2 min.
setting
0.0%
F04.07 Line 2 max. setting 100.0%
F04.08
Corresponding value of line 2 max.
setting
100.0%
F06.00 Pre-torque selection 1 Analogue weighing feedback
F06.01 Up pre-torque bias 50.0%
Set according to actual situation
and debug according to running
effect.
F06.02 Down pre-torque bias 50.0%
F06.03 Up electrical pre-torque gain 1.000
F06.04 Up brake pre-torque gain 1.000
F06.05 Down electrical pre-torque gain 1.000
F06.06 Down brake pre-torque gain 1.000
F12.01 DI1 function 1 Controller enabled (EN)
F12.02 DI2 function 2 UP
F12.03 DI3 function 3 DN
F12.15 DO1 function 2 Controller is running
F12.16 DO2 function 3 Controller is at zero-speed running
F12.17 RLY1 function 14 Controller fault
F13.00 AI1 function 1 Speed setting
F13.01 AI2 function 2 Weighing signal
F13.04 / F13.07 AI1/ AI2 bias 0.0%
Adjust according to actual
situation
F13.05 / F13.08 AI1/ AI2 gain 1.00
F13.06 / F13.09 AI1/ AI2 filter time 0.05s
