hpmont HD5L-4T3P7 User Manual

Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD5L Series Controller User Manual －115－
Code Name Range Default Unit Attributes Setting
F04.03
Line 1 maximum
reference
F04.01－100.0% 100.0% 0.1% ○
F04.04
Corresponding value of
line 1 maximum
reference
0.0－100.0% 100.0% 0.1% ○
F04.05
Line 2 minimum
reference
0.0－F04.07% 0.0% 0.1% ○
F04.06
Corresponding value of
line 2 minimum
reference
0.0－100.0% 0.0% 0.1% ○
F04.07
Line 2 maximum
reference
F04.05－100.0% 100.0% 0.1% ○
F04.08
Corresponding value of
line 2 maximum
reference
0.0－100.0% 100.0% 0.1% ○
Group F05 Speed Parameters (on pages 65
－
67)
F05.00 Multi-speed 0 0.000－F00.02m/s 0.000m/s
0.001
m/s
○
F05.01 Multi-speed 1 0.000－F00.02m/s 0.000m/s
0.001
m/s
○
F05.02 Multi-speed 2 0.000－F00.02m/s 0.000m/s
0.001
m/s
○
F05.03 Multi-speed 3 0.000－F00.02m/s 0.000m/s
0.001
m/s
○
F05.04 Multi-speed 4 0.000－F00.02m/s 0.000m/s
0.001
m/s
○
F05.05 Multi-speed 5 0.000－F00.02m/s 0.000m/s
0.001
m/s
○
F05.06 Multi-speed 6 0.000－F00.02m/s 0.000m/s
0.001
m/s
○
F05.07 Multi-speed 7 0.000－F00.02m/s 0.000m/s
0.001
m/s
○
F05.08 Inspection run speed 0.000－0.630m/s 0.200m/s
0.001
m/s
○
F05.09 Battery driven run speed 0.000－F00.02m/s 0.100m/s
0.001
m/s
○
F05.10
Up forced Dec detection
value
0.0－100.0%(F00.02) 97.0% 0.1% ○
F05.11
Down forced Dec
detection value
0.0－100.0%(F00.02) 97.0% 0.1% ○
F05.12 FDT1 0.0－100.0%(F00.02) 90.0% 0.1% ○
F05.13 FDT2 0.0－100.0%(F00.02) 90.0% 0.1% ○
F05.14 FDT1 delay level 0.0－100.0%(F00.02) 1.0% 0.1% ○
F05.15 FDT2 delay level 0.0－100.0%(F00.02) 1.0% 0.1% ○
F05.16 FAR range 0.0－20.0%(F00.02) 1.0% 0.1% ○
F05.17 Over-speed setting 80.0－120.0%(F00.02) 115.0% 0.1% ×
A
