Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―54― HD5L Series Controller User Manual
6.1 Group D: Display Parameters
Group D is state display parameters. The users can directly check the state parameters by
checking the function code of Group D.
6.1.1 Group D00 System State Parameters
Code Name Description Range
【
factory setting
】
D00.00 Controller series
【
actual value
】
Display HD5L controller series.
D00.01 DSP software version
【
actual value
】
Display the DSP software version.
D00.02 DSP special software version
【
actual value
】
Display the DSP special software version.
D00.03 Panel software version
【
actual value
】
Display the panel software version.
D00.04 Elevator running state
【
actual value
】
Display the elevator running state in 16-bit binary. As following:
Bit15: battery driven run
0: no
1: yes
Bit14: MS terminal 3
0: invalid
1: valid
Bit13: MS terminal 2
0: invalid
1: valid
Bit12: MS terminal 1
0: invalid
1: valid
Bit11: down forced Dec.
input
0: invalid
1: valid
Bit10: up forced Dec.
input
0: invalid
1: valid
Bit9: contactor
feedback input
0: invalid
1: valid
Bit8: brake feedback
input
0: invalid
1: valid
Bit7－bit4: reserved which means “0”
Bit3: analogue run
0: no
1: yes
Bit2: MS run
0: no
1: yes
Bit1: inspection run
0: no
1: yes
Bit0: controller enable
0: disenable
1: enable
123
D00.05
Controller rated current
【actual value】
Display the controller rated current.
D00.06
Controller state
【actual value】
Display the controller state in 16-bit binary. As following:
Bit15: reserved Bit14: reserved
Bit13: stop signal
0: no stop signal
1: stop signal
Bit12: contactor output
0: invalid
1: valid
Bit11: brake output
0: invalid
1: valid
Bit10: ready to run
0: not ready
1: be ready
Bit9: speed arrived
0: no
1: yes
Bit8: auto-tuning
0: no in auto-tuning
1: in auto-tuning
Bit7: run at
zero-speed
0: not at zero-speed
1: at zero-speed
Bit6: zero-speed
signal
0: invalid
1: valid
Bit5&Bit4: acceleration/deceleration/constant
00: constant
11: reserved
01: acceleration
10: deceleration
Bit3: DN
0: no
1: yes
Bit2: UP
0: no
1: yes
Bit1: run/stop
0: stop
1: run
Bit0: controller fault
0: no fault
1: fault
123
