Chapter 4 Electrical Installation Shenzhen Hpmont Technology Co., Ltd
―16― HD5L Series Controller User Manual
4.2 Selection of Main Circuit Peripheral Devices
Please refer to the Table 4-1 for the recommended specifications.
Table 4-1 HD5L series controller I/O wiring specification
Model
Input Protection Main Circuit
Control Circuit
(mm
2
)
MCCB
(A)
Contactor
(A)
Supply Cables
(mm
2
)
Motor Cables
(mm
2
)
HD5L-2S2P2 32 20 4.0 2.5 ≥0.5
HD5L-2S3P7 63 32 4.0 4.0 ≥0.5
HD5L-2T3P7 40 32 4.0 4.0 ≥0.5
HD5L-2T5P5 63 40 6.0 6.0 ≥0.5
HD5L-2T7P5 63 40 6.0 6.0 ≥0.5
HD5L-2T011 100 63 16 16 ≥0.5
HD5L-2T015 125 100 25 25 ≥0.5
HD5L-2T018 160 100 25 25 ≥0.5
HD5L-2T022 200 125 35 35 ≥0.5
HD5L-2T030 200 125 50 50 ≥0.5
HD5L-4T2P2 16 10 1.5 1.5 ≥0.5
HD5L-4T3P7 25 16 2.5 2.5 ≥0.5
HD5L-4T5P5 32 25 4.0 4.0 ≥0.5
HD5L-4T7P5 40 32 4.0 4.0 ≥0.5
HD5L-4T011 63 40 6.0 6.0 ≥0.5
HD5L-4T015 63 40 6.0 6.0 ≥0.5
HD5L-4T018 100 63 10 10 ≥0.5
HD5L-4T022 100 63 16 16 ≥0.5
HD5L-4T030 125 100 25 25 ≥0.5
HD5L-4T037 160 100 25 25 ≥0.5
HD5L-4T045 200 125 35 35 ≥0.5
4.3 Main Circuit Terminals and Wiring
• The bare portions of the power cables must be bound with insulation tapes.
• Ensure that AC supply voltage is the same as controller’s rated input voltage.
Danger
Warning
