6.2.15 Group F14 SCI Communication Parameters
Refer to Appendix B (Page 129) for the communication function.
Code Name Description Range
factory setting
F14.00 Data format 0
5
0
0: 1-8-2 format, no parity, RTU.
1: 1-8-1 format, even parity, RTU.
2: 1-8-1 format, odd parity, RTU.
3: 1-7-2 format, no parity, ASCII.
4: 1-7-1 format, even parity, ASCII.
5: 1-7-1 format, odd parity, ASCII.
F14.01 Baud rate selection 0
5
3
0: 1200bps.
1: 2400bps.
2: 4800bps.
3: 9600bps.
4: 19200bps.
5: 38400bps.
F14.02 Local address 0
247
2
When F14.02 = 0, it means broadcast address.
F14.03 Host PC response time 0
1000
0ms
Detection time of communication timeout
When the time at no communication data exceeds the setting time of F14.04, it will be considered as
E0028 fault (SCI timeout faulty).
• When F14.04 = 0, it will not detect communication time out.
Detection time ofcommunication error
When the time at communication error exceeds the setting time of F14.05, it will be considered as
E0029 fault (SCI faulty).
• When F14.05 = 0, it will not detect the communication error.
6.2.16 Group F15 Display Control Parameters
Code Name Description Range
factory setting
F15.00 Language selection 0,1
0
It defines the displaying language on the LCD panel.
0: Chinese.
1: English.
2－9: Reserved.
F15.01 LCD panel display contrast 1
10
5
To select LCD display contrast.
F15.02 Run display parameter 1 set 0
32
5
Run display parameter 2 set
F15.04 Run display parameter 3 set 0
32
10
Run display parameter 4 set
F15.06 Run display parameter 5 set 0
32
0
Run display parameter 6 set
6
To Next Page
