Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―82― HD5L Series Controller User Manual
6.2.18 Group F17 Fault Protect Parameters
Motor overheated fault (F17.00
－
F17.02)
It can connect the electronic thermistor embedded motor stator coils to the controller’s analogue
input AI4 in order to protect motor overheating. The connection is shown as 4.5.3 of I/O Card
Terminal Connection.
Code Name Description Range
【
factory setting
】
F17.00
Input voltage at motor overheated
0.00－10.00【0.00V】
F17.01 Thermistor type 0
－
2
【
0
】
0: Does not detect the motor overheating (NC).
1: Positive charateristic (PTC).
• When AI4 input is exceeded F17.00, the controller will alarm E0020 fault (motr overheated).
2: Negative charateristic (NTC).
• When AI4 input is less than F17.00, the controller will alarm E0020 fault (motr overheated).
Note: Only when correctly set CN2 and CN3 of I/O card will do the motor overheated detection.
F17.02 Threshold resistance at motor overheated 0
－
10.0
【
5.0kΩ
】
Input and output phase loss fault (F17.03
－
F17.06)
Code Name Description Range
【
factory setting
】
F17.03
The detect base of lack of input
0－100【30%】
F17.04 The detect time of lack of input 0.0
－
5.0
【
1.0s
】
F17.03 value is a percentage of the controller’s rated voltage.
When the controller detects certain input voltage not hit the preset detect base (F17.03) and exceed
the preset detect time (F17.04), the controller will alarm E0015 fault (lack of input).
• When F17.03 or F17.04 is set as 0 or in the battery driven run mode, the controller will not detect
input phase loss fault.
F17.05 The detect base of lack of output 0
－
100
【
20%
】
F17.06
The detect time of lack of output
0.0－20.0【3.0s】
F17.05 value is a percentage of the controller’s rated current.
When the controller detects certain output current not hit the preset detect base (F17.05) and exceed
the preset detect time (F17.06), the controller will alarm E0016 fault (lack of output).
• When F17.05 or F17.06 is set as 0, the controller will not detect output phase loss fault.
123
Motor fault (F17.07)
Code Name Description Range
【
factory setting
】
F17.07
Motor overload protect factor
20.0－110.0【100.0%】
The motor overload protection factor can be set as 100% when the controller drives a motor of the
same power class.
To protect the motor when the motor power is smaller than the standard matched power, you need to
set a proper motor overload protection factor (F17.07). The factor can derive from the following
formula:
Motor overload protect factor
(
F17.07
)
=
Motor rated current
(
F07.02 or F10.03
)
Controller rated output current
× 100%
