6.2.6 Group F05 Speed Parameters
Code Name Description Range
【
factory setting
】
F05.00 Multi-speed 0 0.000
－
F00.02
【
0.000m/s
】
F05.01
Multi-speed 1
0.000－F00.02【0.000m/s】
F05.02 Multi-speed 2 0.000
－
F00.02
【
0.000m/s
】
F05.03
Multi-speed 3
0.000－F00.02【0.000m/s】
F05.04 Multi-speed 4 0.000
－
F00.02
【
0.000m/s
】
F05.05
Multi-speed 5
0.000－F00.02【0.000m/s】
F05.06 Multi-speed 6 0.000
－
F00.02
【
0.000m/s
】
F05.07
Multi-speed 7
0.000－F00.02【0.000m/s】
F05.00－F05.07 define the MS running speed which use in MS run mode. F00.02 defines the elevator
rated speed.
F05.08
Inspection run speed
0.000－0.630【0.200m/s】
It defines the elevator’s running speed in the inspection mode.
F05.09
Battery driven run speed
0.000－F00.02【0.100m/s】
It defines the elevator’s running speed in the battery driven run mode.
F05.10
Up forced Dec detection value
0.0－100.0 (F00.02)【97.0%】
It defines the speed detection value at the forced
switch action.
• After forced switch act, the running speed exceeds
Dec detection value, and decelerate to F05.22
(creeping speed) according to F03.12 (abnormal
Dec speed).
• Properly set this parameter to avoid climbing
elevator at elevator up.
F05.11
Down forced Dec detection value
0.0－100.0 (F00.02)【97.0%】
To avoid plunging elevator at elevator down. Refer to parameter F05.10.
Shaft top space
Contact board
Top floor
Car
Up forced
Dec switch
6
