Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―124― HD5L Series Controller User Manual
Code Name Range Default Unit Attributes Setting
27: Output terminal state
28: MODBUS state
29: Total power-on
time(Hour)
30: Total running time(Hour)
31,32: Reserved
Group F16 Enhance Function Parameters (on pages 81
82)
F16.00
Zero-speed running
signal delay time
0.00－10.00s 0.30s 0.01s ×
F16.01
Zero-speed signal delay
time
0.00－10.00s 0.30s 0.01s ×
F16.02
Current keep time after
stop command
0－9999ms 0ms 1ms ×
F16.03 Fan control mode
0: Auto stop
1: Immediately stop
2: Run when power on
0 1 ○
F16.04 Fan keep time 0.0－600.0s 30.0s 0.1s ○
F16.05 Brake unit action voltage
220V: 380－450V
380V: 630－750V
Depend on
controller
model
1V ×
F16.06
Contator fault detect
time
0.0－10.0s 2.0s 0.1s ×
F16.07
Multi-speed inspection
select
0－7 0 1 ×
F16.08 Zero speed threshold 0.001－0.010m/s 0.003m/s
0.001
m/s
○
F16.09
The selection at the fault
of Motor overheat
0: Report E0020 after motor
stop
1: Report E0020 at once
0 1 ○
F16.10
The coefficient of
frequency
demultiplication of
HD-PG9-SC-FD
1－256 1 1 ×
F16.11－F16.24 Reserved
Group F17 Fault Protect Parameters (on pages 82
85)
F17.00
Input voltage at motor
overheated
0.00－10.00V 0.00V 0.01V ×
F17.01 Thermistor type
0: NC
1: Positive
2: Negative
0 1 ×
F17.02
Threshold resistance at
motor overheated
0.0－10.0kΩ 5.0kΩ 1.0kΩ ×
F17.03
The detect base of lack
of input
0－100%(controller rated
voltage)
30% 1% ×
F17.04
The detect time of lack
of input
0.0－5.0s 1.0s 1.0s ×
To Next Page
