hpmont HD5L-4T3P7 User Manual

Appendix B Communication Protocol Shenzhen Hpmont Technology Co., Ltd
―138― HD5L Series Controller User Manual
Control word
(Bit)
Value Definition Function description
bit0
1 Run command enabled
This bit co-work with controller’s enable bit to run
the controller. The controller will close the running
contactor, release the brake and start to run. This
bit becomes invalid only after the controller stops.
0 Run command disabled Stop output and output released brake signal.
bit1
1 Down
Elevator running direction. The same function as
terminal UP/DN.
0 Up
bit2
1 No emergency stop Controller runs normally.
0 Emergency stop Controller controls drive to stop.
bit3
1 SCI control enabled
If the terminal EN is enabled, controller can run
normally.
0 SCI control disabled Drive stop output and release brake signal.
bit4
1 With new run speed
Indicates a change in running speed, as
determined by main setting.
0 Without new run speed Keep present speed.
bit5 0 Reserved
bit6
1 Reset enabled Fault reset control
0 Reset disabled
bit7
1 Reserved
0
Main setting of this frame
is speed
Main setting of this frame is speed.
Bit8－bit11 0 Reserved
bit12
1
Inspection run mode
enabled
Indicates inspection running mode. Function the
same as terminal INS.
0
Inspection run mode
disabled
bit13
1 Battery run mode enabled
Indicates battery driven mode. Function the same
as terminal BAT.
0 Battery run mode disabled
bit15, bit14 0 Reserved
Drive main setting is as following:
Control word (bit7) Run setting data value Description
0
0 Speed corresponding to parameter F05.00
1 Speed corresponding to parameter F05.01
2 Speed corresponding to parameter F05.02
3 Speed corresponding to parameter F05.03
4 Speed corresponding to parameter F05.04
5 Speed corresponding to parameter F05.05
6 Speed corresponding to parameter F05.06
7 Speed corresponding to parameter F05.07
1 0 Reserved
