7.
At the end of the test, if the detected phase sequence is
incorrect, the instrument displays a screen like the one
shown to the side (result "213") and the “NOT OK”
message.
123 15/10 – 18:04
TN
2 1 3
NOT OK
1T
MODE
8.
At the end of the test, if the two detected voltages are in
phase (phase concordance between two distinct
three-phase systems), the instrument displays a screen
like the one to the side (result "11-") and the “OK”
message.
123 15/10 – 18:04
TN
1 1 -
OK
1T
MODE
9. Press the SAVE key to store the test result in the instrument’s memory (see § 7.1) or
the ESC/MENU key to exit the screen without saving and go back to the main
measuring screen.
