HT EASYTEST - Anomalous Situations

EASYTEST-COMBI519
EN - 48
6.6.6. Anomalous situations
1.
If the instrument detects a frequency higher than the
maximum limit (63Hz), it does not carry out the test and
displays a screen like the one to the side.
RCD 15/10 – 18:04
TT
T
Ut
=
=
- - -
- - -
ms
V
FREQ. = >63Hz
VL-PE=231V
VL-N=234V
Freq. out of range
X1
30mA
↑
MODE
In
Type
Ut
2.
If the instrument detects a L-N or L-PE voltage lower
than the minimum limit (100V), it does not carry out the
test and displays a screen like the one to the side.
Check that the system being tested is supplied
RCD 15/10 – 18:04
TT
T
Ut
=
=
- - -
- - -
ms
V
FREQ. = 0.00 Hz
VLPE=<100V
VL-N=<100V
Voltage <100V
X1
30mA
↑
MODE
In
Type
Ut
3.
If the instrument detects a L-N or L-PE voltage higher
than the maximum limit (265V), it does not carry out the
test and displays a screen like the one to the side.
Check the connection of measuring cables.
RCD 15/10 – 18:04
TT
T
Ut
=
=
- - -
- - -
ms
V
FREQ. = 50.00 Hz
VLPE=>265V
VL-N=>265V
Voltage >265V
X1
30mA
↑
MODE
In
Type
Ut
4.
If the instrument detects a dangerous voltage on PE
conductor, it provides the warning screen shown to the
side and blocks the execution of the tests. Check the PE
conductor and earth connection efficiency.
RCD 15/10 – 18:04
TT
T
Ut
=
=
- - -
- - -
ms
V
FREQ. = 0.00Hz
VL-PE=- - -V
VL-N=- - -V
Voltage on PE
X1
30mA
↑
MODE
In
Type
Ut
