HTC 1500 ixT
Machine description
3.0 11
3
7
4
3
4
1
5
8
9
10
11
6
2
12
Figure 3-1 The front of the machine
1. Safety bar
2. Water tank
3. Drive motor
4. Wheel
5. Grinding cover
6. Headlight
7. Serial number
8. Grinding motor
9. Filler cap water
10. Lifting eye
11. Seat
12. Control panels
