HTC 1500 ixT
Machine description
3.0 19
A
B
Figure 3-6 Safety bar
Warning!
There is a risk of trapping when locking the bar. Ensure that you
do not place your fingers between the bar and the foot pedal.
Note!
Check the bar each time you lift to avoid the grinding head being
damaged or causing injury or damage.
3.5. Mist Cooler System
The Mist Cooler system consists of a water tank, particle filter,
pump, pressure equaliser, nozzles and drainage valve. The system
is powered by 230 V and can only be used when the machine is
connected to the mains power.
Refill with water via the filler cap in the water tank, see Figure
3-1 on page 11.
