HTC 1500 IXT - Changing Grinding Tools

HTC 1500 ixT
Operation
3.0 23
Figure 4-1 Fitting grinding tools
2. Lock the grinding tool into the tool holder by giving
it a few light taps with a rubber hammer, see Figure
4-2 on page 23.
Figure 4-2 Locking grinding tools
4.4.2. Changing grinding tools
1. Remove the grinding tool by giving it a few light taps
with a rubber hammer so the locking mechanism releases,
see Figure 4-3 on page 24. Then draw the tool up out of
the guide slot.
