Operation
HTC 1500 ixT
22 3.0
Warning!
Disconnect the electrical supply and raise the grinding head when
changing tools or repairing the machine.
• Raise the grinding head to access the tools, see Control
panel - left on page 13.
• Ensure the bar is in the locked position, see under Safety
bar on page 18.
Warning!
There is a risk of crushing when locking the bar. Ensure that you
do not place your fingers between the bar and the foot pedal.
4.4. Fitting and replacing grinding tools
Warning!
Disconnect the electrical supply and raise the grinding head when
changing tools or repairing the machine.
Warning!
The tool becomes very hot during use. Leave the machine to stand
for a short while and use protective gloves when removing the
tools.
As the machine is equipped with the patented EZchange tool
system, fitting and replacing grinding tools is quick and easy. The
tool systems consists of wings on which diamond grinding tools are
fitted without the need for screws.
4.4.1. Fitting grinding tools
1. Slide the grinding tool diagonally from above down into
the appropriate guide slot on the tool holder, see Figure
4-1 on page 23. Then push the tool fully into the guide
slot.
