Figure 3-5 Adjusting the seat
3.4. Safety bar
The machine is equipped with a foot pedal (A) that functions as a
mechanical safety bar for the grinding head. When transporting the
machine and changing tools, the grinding head must always be in
the raised position.
• Raise the grinding head and ensure that the bar (B) is in the
locked position.
• Lower the grinding head by pressing the pedal (A) in order
to release the bar (B).
