HTC 1500 IXT - Page 45

HTC 1500 ixT
Operation
3.0 35
Note!
The ignition key must be in "O" position when the cable is
connected to an electrical socket.
1. Pull out the cable. Ensure that at least two turns are left
on the cable winder as a safety margin. Release the cable
slowly back until it locks.
2. Plug the cable into an electrical socket, see Figure
4-9 on page 35.
3. Secure the strain relief device in a suitable position
in order to take the strain off the cable, see Figure
4-9 on page 35.
Figure 4-9 Cable and strain relief device
4. Check if the emergency stop switches have been pressed.
Reset the switches by turning them 45°.
5. Place your feet on the foot marks indicated, see Figure
4-10 on page 36.
