Page #75 background imageLoading...
Page #75 background image
75
LP-520 REV. 5.1.17
could result in property damage, serious personal injury, or death.
6. Fill the condensate trap with fresh water prior to reassembly on the appliance.
7. Install the condensate trap on the condensate hose from the heat exchanger. Use the hose clamp to secure the trap. Attach the clear
plastic hose onto the hose barb. Reinstall the condensate hose clamp to detach the condensate trap from the drain tube.
Do not operate the appliance without the clear hose attached from the hose barb to the pressure switch. Failure to follow this warning
could result in property damage, serious personal injury, or death.
8. If a condensate neutralizer kit is installed with the appliance, check the assembly when cleaning the condensate trap, and replenish
the limestone chips if necessary. When replacing the limestone chips, take care to ensure chips are no smaller than ½” to avoid
blockage in condensate piping (for piping details, refer to condensate neutralizer installation instruction.)
9. Check condensate piping for sagging and/or leakage. Repair any sags or leaks before restoring power to the appliance.
It is very important that the condensate piping be no smaller than ¾”. To prevent sagging and maintain pitch, condensate piping should
be supported with pipe supports, and pitched ¼” per foot to allow for proper drainage.
The condensate line must remain unobstructed, allowing free flow of condensate. If condensate freezes in the line, or if line is
obstructed in any other manner, condensate can exit from the tee, resulting in potential water damage to property.
10. If the appliance has a condensate pump, ensure the pump operates properly before considering maintenance complete.
REPLACEMENT PARTS
NUMBER
DESCRIPTION
PART NUMBER
NUMBER
DESCRIPTION
PART NUMBER
B-1
M3 X 6 PH + MS
7855P-384
B-10
M4 X 12 TH + M/S
7855P-393
B-2
M4 X 8 PH + Self Tapping
7855P-385
B-11
M4 X 14 PH + Self Tapping
7855P-394
B-3
M4 X 8 TH + Self Tapping
7855P-386
B-12
M4 X 15 PW + M/S
7855P-395
B-4
M4 X 8 TH + MS
7855P-387
B-13
M4 X 20 TH + Self Tapping
7855P-396
B-5
M4 X 10 FH + M/S
7855P-388
B-14
M5 X 14 Flange Bolts M/S
7855P-397
B-6
M4 X 10 TH + Self Tapping
7855P-389
B-15
M5 X 10 TH+ M/S
7855P-453
B-7
M4 X 10 TH + M/S
7855P-390
B-16
M4 X 9 PH.PW + Self Tapping
7855P-296
B-8
M4 X 10 Flat Head
7855P-391
N-1
M4 Nut
7855P-398
B-9
M4 X 12 PH + M/S
7855P-392
N-2
M5 Nut
7855P-399
Table 33 Replacement Bolts and Nuts
